Newton Fractals
Newton’s method utilizing the Jacobian matrix
Outline
- Write the class fractal2D for a system of two equations with two variables
- Write the method _Newton_ which takes an initial guess as input
- Write the method _getzeroes_ to store a zero or a divergence given by _Newton_
- Write the method _plot_ to run _Newton_ for multiple initial guesses and visualize the results in a figure
- Write the method _simpNewton_ which will compute the Jacobian only once
- Compute the derivatives numerically for the Jacobian matrix and add these derivatives as an optional argument in _init_
- Write the method _itPlot_ which show dependence between initial values and iterations needed to reach convergence
- Test the code with two further functions
Raw code
import scipy as sp
import numpy as np
import pylab as pl
from sympy import symbols, diff
from scipy.linalg import solve
from sympy import *
def f(x):
return (x[0]**3)-(3*x[0]*x[1]**2)-1
def g(x):
return (3*x[0]**2*x[1]-(x[1]**3))
class fractal2D(object):
def __init__ (self, f, g):
self.f = f
self.g = g
self.tol= 1.e-9
self.listempty=True
self.xz=[]
def __call__(self, x):
return f(x), g(x)
def __repr__(self):
return ("({},{})".format(self.f,self.g))
def __Jacobian__ (self, x):
f, g = self.f, self.g
fvec = np.array([f,g])
xold=x
xl = symbols('x0 x1')
J = np.zeros([len(fvec),len(x)])
for i in range(2):
for j in range(2):
Jsym = diff(fvec[i](xl),xl[j])
J[i,j] = Jsym.subs([(xl[0],x[0]),(xl[1],x[1])])
return J
def __Newton__(self,x0):
x = np.transpose(x0)
xt = np.transpose(x)
f,g,tol= self.f,self.g,self.tol
for i in range(10000):
prev=xt #row vector
fvec = np.array([f(xt),g(xt)])
J = self.__Jacobian__(prev)
xt= xt - np.linalg.solve(J,fvec) #column vector
if abs(xt-prev).all() < tol:
return xt
else:
return "No conv detected"
def __getzeroes__(self, xintial):
if self.listempty==True:
self.xz.append(self.__Newton__(xintial[0]))
self.listempty=False
for i in range(0,len(xintial)):
N = self.__Newton__(xintial[i])
if type(N)== str:
self.xz.append(N)
else:
C = abs(self.xz-N) > self.tol
for i in range(len(C)):
if C[i].any() != True:
break
else:
self.xz.append(N)
return self.xz
def __plot__(self, N, a,b,c,d, S):
xvalues = np.linspace(a,b,N)
yvalues = np.linspace(c,d,N)
X, Y = np.meshgrid(xvalues, yvalues)
P=np.zeros((N,N), dtype='float,float')
for i in range(N):
for j in range(N):
P[i,j]=(X[i,j],Y[i,j])
P=np.transpose(P)
A=np.zeros(np.shape(P))
B=np.zeros(np.shape(P))
for j in range(N):
for k in range(N):
if S != True:
current=(self.__Newton__(tuple(P[j,k])))
else:
current=(self.__SimplifiedNewton__(tuple(P[j,k])))
if isinstance(current, (str)):
raise TypeError(current)
A[j,k]=current[0]
B[j,k]=current[1]
print(k)
print(j)
pl.pcolor(A)
pl.pcolor(B)
return A,B
def __SimplifiedNewton__(self,x0):
x = np.transpose(x0)
xt = np.transpose(x)
f,g,tol= self.f,self.g,self.tol
J = self.__Jacobian__(xt)
for i in range(1000000):
prev=xt #row vector
fvec = np.array([f(xt),g(xt)])
xt= xt - np.linalg.solve(J,fvec) #column vector
if abs(xt-prev).all() < tol:
return xt
else:
return "No conv detected"
def __SNM__(self,x0):
x = np.transpose(x0)
xt = np.transpose(x)
f,g,tol= self.f,self.g,self.tol
J = self.__Jacobian__(xt)
for i in range(1000000):
prev=xt #row vec
fvec = np.array([f(xt),g(xt)])
xt= xt - np.linalg.solve(J,fvec) # column vector
if abs(xt-prev).all() < tol:
return xt
else:
return "No conv detected"
def __itPlot__(self,N,a,b):
xvalues = np.linspace(a,b,N)
values= []
for i in range(len(xvalues)):
values.append(np.array([[xvalues[i]],[xvalues[i]]]))
A=[]
for i in range(len(xvalues)):
A.append(self.__Newton__(values[i])[1])
pl.plot(xvalues,A,'.')
pl.xlabel("Starting Value")
pl.ylabel("Iteration needed")
pl.show()
return A
I=fractal2D(f, g)
#print(I.__Jacobian__(np.array([2,3])))
#define x0 as list of row vectors containing initial points
A=tuple((5.1,6.5))
T = I.__Newton__(A)
#T = I.__SNM__([[5],[6]])
#for i in range(-1000,1000):
# if i==0:
# i+=1
As=I.__itPlot__(250,-50,50,-50,50, True)
print(T)
